STEP 14
BOLT WH
5/16x1 1/2
(4)
WASHER
LOCK EXT
8x19
(4)
NUT BARREL
WH 5/16x7/8
(4)
WASHER
LOCK EXT
12x19
(4)
WASHER LOCK EXT 8x19
3/&6
BOLT WH 5/16x1 1/2
3/&6
WASHER LOCK EXT 12x19
3/&6
NUT BARREL WH 5/16x7/8
3/&6
.
K1 - UPPER WALL RAIL - W104116
5/8"x5 1/4"x45 1/2" (16x134x1156)

