STEP 17
WASHER
LOCK EXT
8x19
(2)
LAG SCREW
WH 5/16x2
(2)
LAG SCREW WH 5/16x2
3/&
WASHER LOCK EXT 8x19
3/&
LAG SCREW WH 5/16x2
3/&
WASHER LOCK EXT 8x19
3/&
0
0
M2 - SMALL WALL RAIL - W104135
5/8"x3 3/8"x5 3/8" (16x86x138)

M12 - WALL RAIL - W104136
5/8"x3 3/8"x25 1/4" (16x86x642)

