Backyard Discovery TUCSON 65411B - Page 26

SWING BEAM
ASSEMBLY
Ǣǻrƻˢ
BOLT WH
5/16x1 3/4
(2)
H100011
(1) SWING BEAM SUBASSEMBLY (1) SWING BEAM END
SUBASSEMBLY
˟˟ˤ  ʹɮˡʺ
ŗȕǻDNJNJrĵ˚˦ˀ˧˃
˟ˠˠ ʹɮˡʺ
Dŷĵǻ˚ˠˢˀˣ˃
SWING BEAM SUBASSEMBLY
SWING BEAM END
SUBASSEMBLY
NUT BARREL WH
5/16x7/8
(2)
H100005
˟˟˥ ʹɮˠʺ
ŗȕǻDNJNJrĵ˚ˠˠˀˡ˃
˟ˠˣ ʹɮˠʺ
Dŷĵǻ˚ˡˠˀˡ˃
BOLT WH
5/16x2 1/2
(1)
H100014
NUT BARREL WH
5/16x1 1/2
(1)
H100006
