Backyard Play Systems 4431 - Roof Frame Assembly

55
FORT
BAY WINDOW
FORT
BAY WINDOW
30 mm Wood Screws
x8
x4
2855-CC
5/8 x 3-1/4 x 12-7/16"
Flush Flush
Flush
OUTSIDE VIEW
#8 x 3/4" Flat Head
Phillips Screws
x20
x2
PF2990
2855-CC
EQUAL
SIDE VIEW
EQUAL
EQUAL
EQUAL
OUTSIDE VIEW
