Backyard Play Systems 4431 - Accessories: Climbing Rope Installation

60
TELESCOPE INSTALL
STEERING WHEEL INSTALL
1-1/2" Lag Bolt
Flat Washer
Steering Wheel Cap
DO NOT OVER-TIGHTEN LAG BOLTS.
x1
WS 4412
Install WS 4412 inside fort.
Telescope and Bracket
Telescope
Bracket
Any Top Rail
Mounting Screw
x1
WS 4610
1. Position Mounting Bracket in desired location
(any Top Rail).
2. Attach Mounting Bracket to Top Rail using the
Mounting Screw provided.
3. Insert the Telescope into the Mounting Bracket
as shown.
