Locate ag base EQUALLY from top, bottom
and end of upper top rail (Fig. 1).
Attach each ag with 4 screws.
1
2
Fig. 1
3/4" Truss Head
Screws
x4
EQUAL
EQUAL
FRONT SIDE
NOTE:
Flush edge of slide to the
end of deck boards.
for AND sliDes
2660
sP 2680
Secure Slide using (4) 1-3/4"
Pan Head Screws through slide
and into deck board.
Locate Slides centered in the opening of the terrace.
1
2
1-3/4" Pan Head Wood Screw x8
Flush
Deck Board
To Next Page
