Backyard YardLine ASTON - Page 16

16
48"
(121,9 cm)
3/4"
(1,9 cm)
4"
(10,2 cm)
3/4"
(1,9 cm)
12"
(30,5 cm)
6"
(15,2 cm)
23-7/8"
(60,6 cm)
4"
(10,2 cm)
6"
(15,2 cm)
Forsquarenessmaintain3/4"
measurementalongpaneledges.
Forsquarenessmaintainush
alongpaneledges.
Place center 48"x72" panel on frame
as shown with primed side facing up.
Nail using 2" nails 6" apart on edges
and 12" apart inside panel.
6
Place end 23-7/8"x72"panel on frame
as shown with primed side facing up.
Nail using 2" nails 6" apart on edges
and 12" apart inside panel.
7
You have nished building your back wall.
FINISH
9
48 x 72"
(121,9 x 213,4 cm)
23-7/8 x 72"
(60,6 x 213,4 cm)
x1 x1
x75
BACK WALL PANELS
PARTSREQUIRED:
2" (5,1 cm)
DOOR
8
Carefully ip the BACK wall over.
DOOR
3/4"GAUGE
BLOCK
GAA
3/4"GAUGE
BLOCK
Flush
Primed
sideup
Primed
sideup
