Backyard YardLine ASTON - DOORS

1 x 3 x 5" (2,5 x 7,6 x 12,7 cm)
x1
GAA
42
Orient parts as shown on at surface. 3/8"offsetistotop.Lookforred
(right)andgreen(left)onhingeboard.
PARTSREQUIRED:
x1x1
Left Door Right Door
BEGIN
1
DOORS
1-1/4" (3,2 cm)
2
3
Attach temporary support OO with 3" screws in middle and at ends as shown.
Tighten securely.
Attach temporary support GAA with two 1-1/4" screws as shown.
Tighten securely.
HINT:
Lookfor3/8"SPACER
attachedtodoors.
OO
GAA
Makesurespacer
isattached.
Tightenscrews
securely.
OFFSET
(4)3"(7,6cm)
Screws
Screws
1-1/4"(3cm)
Bottomedgesush.
NOTE:
Screw hole
will be
used later.
3/8"
(1 cm)
3/8"
(1 cm)
3/8"
(1 cm)
3/8"
(1 cm)
OFFSET
GREEN RED
3" (7,6 cm)
OO
x1
2 x 3 x 69" (5,1 x 7,6 x 175,3 cm)
3/4"
(1,9 cm)
23-1/2"
(59,7 cm)
23-1/2"
(59,7 cm)
3/4"
(1,9 cm)
x2
x4
