Backyard YardLine ASTON - Page 49

19/32 x 2-1/2 x 91" (1,5 x 6,3 x 231,1 cm)
x2
BSA
49
2" (5,1 cm)
TRIM
PARTSREQUIRED:
WINDOWS
Do not nail into window ange.
3
4
5
Center BSA over door. Secure using (7) 2" nish nails as shown.
Position EY at ends and in between window frame as shown. Secure using (8) 2" nish nails.
Remove1-1/4"screws.
Position BSA centered on window frame as shown. Secure using (4) 2" nish nails.
x4
19/32 x 2-1/2 x 9" (1,5 x 6,4 x 22,9 cm)
EY
x19
EYx4
26-1/2"(78,7cm)
Centered
Removescrews Removescrews
MarkCenter
Flush
Flush
BSA
Centered
3/4"
(1,9 cm)
BSA
Centered
FRAMING
BEYOND
FRAMING
BEYOND
