CHAPTER 3 ENGINE ACCESSORIES1025H TRACTOR
3
NOTE
• Refer to the paragraph ”SEPARATION OF THE ENGINE AND THE FRONT AXLE BRACKET" for
operation up to this step.
• When removing the radiator, take care not to damage the radiator cores and oil cooler if equipped.
1.3 SPECIFICATIONS
1.4 REMOVAL OF THE RADIATOR
1. Drain the anti freeze through the drain plug.
2. Release the clamp and remove the upper hose.
3. Release the clamp and remove the lower hose.
4. Release the hose clamp and remove the water drain hose.
Description 1025H
Radiator core type CF (Wave n)
Core train number 2 trains
Radiator n pitch 2 mm
Thermal radiator area 6.2530 m
2
Pressure valve opening pressure 0.9 ± 0.15 kgf/cm
2
Coolant capacity 5.2 ℓ (Contains in cylinder block), Radiator : 2.38 ℓ
Test pressure 1.5 kgf/cm
2
