HOW TO USE THIS MANUAL
1. Target readers
This manual is intended for technicians with mid to high level of service knowledge and skills for BAD BOY
TRACTORS. Make sure to understand this manual fully for rapid and accurate inspection and service.
2. Order of contents
This manual is a single book for the 4025H/4035H/4035CH TRACTOR and contains several useful chapters
such as General Information, Engine, Clutch, Transmission, Front Axle, Hydraulic System, Electric System.
Information and diagrams in this manual are described based on the standard model so they may be different
fromyourvehicleduetodifferentspecicationsbymodels.However,thesameinstructionsshouldbefollowed
for service.
3. Body structure of this manual
This manual is structured as follows:
< Lower section >
< Upper section >
CHAPTER 3 TRANSMISSION4025H/4035H/4035CH TRACTOR
K42W416A K42W419A
7. Remove the footstep (1) and fuel tank (2). 10. Remove the release bearing sleeve (1) and lift
the shuttle shaft (2) to separate it from the fork.
40BW-202010
3
-
59
K42W418A
9. Remove the brake rod (1), brake pedal (2),
footstep support assembly (3) and clutch pedal (4).
11. Unscrew the clutch housing & transmission case
mounting bolts (1)(8EA) & nuts (2)(2EA) and
remove the clutch housing (3).
K42W421B
1
2
3
4
5
