Bad Boy 40 Series User Manual

40BW-202010
1
-
42
CHAPTER 1 GENERAL INFORMATION 4025H/4035H/4035CH TRACTOR
8.2.7
CHECKING INSTRUMENT CLUSTER SIGNALS
1. Turn the ignition switch to the START position.
2. Check that the gauges and signals are working
properly.
3. If not, check the corresponding lamp and electric
circuit.
4. If necessary, replace the part with a new one.
B40W107A
ROPS MODEL
K3CW109A
CABIN MODEL
8.2.8 CHANGING ENGINE OIL
1. Remove the drain plug (1) to drain engine oil.
2. Fit the drain plug and tighten it to 50 N.m (37
lb.ft).
3. Add clean oil with proper viscosity to the
crankcase.
CAUTION

Make sure to stop the engine before chang-
ing engine oil.

Make sure that the engine is sufficiently
cooled down enough to touch by a hand.
F42W118A
4. Wait for 15 minutes and check the oil level. The
oil level should be up to the upper limit on the
dipstick (2).
F42W119A

Bad Boy 40 Series Specifications

General

Brand	Bad Boy
Model	40 Series
Category	Tractor
Language	English
