Service Parts Manual
REAR AXLE
Page S-2
Service Parts Manual
634510 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 631810 INDEPENDENT DIFFERENTIAL, MANUAL (INCLUDES ITEMS 2 - 4)........ 1
2 * OIL FILL PLUG (NOT ILLUSTRATED)..................................................... 1
3 * OIL DRAIN PLUG (NOT ILLUSTRATED)................................................. 1
4 * FLANGED HEX BOLT .............................................................................. 8
5 636438 AXLE ASSEMBLY........................................................................................... 2
6
7
8 635732 DIFFERENTIAL ANTI-ROTATION PLATE SPACER ..................................... 1
9 635730 DIFFERENTIAL MOUNTING PLATE RING.................................................... 1
10 635793 FLANGED HEAX HEAD BOLT, 3/8" - 16 X 3" LG........................................... 6
11
12
13 616052 HUB WASHER, 3/8"........................................................................................ 2
14 626448 CASTELLATED NUT, M16 - 1.5...................................................................... 2
15 10387G1 COTTER PIN, 0.125" X 1.5" LG...................................................................... 2
