Service Parts Manual
ELECTRICAL SYSTEM
Page J-2
Service Parts Manual
634510 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 632232 MAIN HARNESS............................................................................................. 1
2 632738 FUSE BOX...................................................................................................... 1
3 12547G4 HEX HEAD CAP SCREW, M6 - 1 X 30MM LG............................................... 2
4
5 632683 DC - DC CONVERTOR (INCLUDES ITEMS 6 - 8)......................................... 1
6 * FLAT WASHER ........................................................................................ 2
7 * HEX NUT.................................................................................................. 2
8 * CONNECTOR........................................................................................... 1
9 632866 TERMINAL BRACKET.................................................................................... 1
10 633235G01 JUNCTION BLOCK, STUD (BLK), 5/16" ........................................................ 1
11 633235G02 JUNCTION BLOCK, STUD (RED), 5/16"........................................................ 1
12 00414G6 HEX HEAD CAP SCREW, 1/4" - 20 X 3/4" LG ............................................... 2
13 01110G01 FLAT WASHER, 1/4"....................................................................................... 2
14 14390G4 LOCK NUT, 1/4" - 20....................................................................................... 2
15 306527 PAN HEAD SCREW, #10 - 24 X 3/4" LG ........................................................ 4
16 00660G5 FLAT WASHER, #10....................................................................................... 4
17 14390G10 LOCK NUT, #10 - 24 ...................................................................................... 4
18 31539G1 NYLON CLAMP (NOT ILLUSTRATED) .......................................................... 20
To Next Page
