Bad Boy MZ Magnum 54 User Manual

This manual applies to the following equipment:
Bad Boy Outlaw Series Bad Boy Outlaw Extreme Series
Outlaw 5400 54˝ 810cc Vanguard Outlaw Extreme 5400 54˝ 824cc Kohler EFI
Outlaw 6100 61˝ 810cc Vanguard Outlaw Extreme 6100 61˝ 824cc Kohler EFI
Outlaw 5400 54˝ 747cc Kohler Confidant Outlaw Extreme 5400 54˝ 852cc Kawasaki FX-850
Outlaw 6100 61˝ 747cc Kohler Confidant Outlaw Extreme 6100 61˝ 852cc Kawasaki FX-850
Outlaw 5400 54˝ 726cc Kawasaki FX-730 Outlaw Extreme 7200 72˝ 852cc Kawasaki FX-850
Outlaw 6100 61˝ 726cc Kawasaki FX-730 Outlaw Extreme 6100 61˝ 993cc Vanguard
Outlaw Extreme 7200 72˝ 993cc Vanguard
72˝ Blade Hi-Lift Fusion Gator Blade Wave Blade
038-7230-00 038-5400-00 038-7215-00
61˝ Blade Hi-Lift Fusion Gator Blade Wave Blade
038-6080-00 038-6081-00 038-6090-00
54˝ Blade Hi-Lift Fusion Gator Blade Wave Blade
038-0001-00 038-0003-00 038-5220-00
Deck Belt 72˝ 61˝ 54˝
041-0202-00 041-0178-00 041-1650-00
Drive Pump Belt 041-5048-00
Vanguard 993cc Oil Filter Air Filter (Inner) Air Filter (Outer)
063-8018-00 063-8020-00 063-8019-00
Kawasaki 852cc Oil Filter Air Filter (Inner) Air Filter (Outer)
063-8017-00 063-8020-00 063-8019-00
Kawasaki 726cc Oil Filter Air Filter (Inner) Air Filter (Outer)
063-8017-00 06390100-00 063-9005-00
Vanguard 810cc Oil Filter Air Filter (Inner) Air Filter (Outer)
063-8018-00 063-8020-00 063-8019-00
Kohler 747cc Oil Filter Air Filter
063-54008-00 063-5005-00
Kohler 824cc EFI Oil Filter Air Filter
063-54008-00 063-8019-00
Motor Oil 10W-30 Motor Oil – Bad Boy Synthetic Blend Motor Oil Recommended
Transaxle Hydro Oil Outlaw Extreme Outlaw
(20W-50) 4.75 quarts per transaxle 4 quarts per transaxle
Transaxle Oil Filters Outlaw Extreme: 063-1060-00 Outlaw: 063-1070-00
COMMONLY USED ITEMS AND PART NUMBERS
PAGE 3

Bad Boy MZ Magnum 54 Specifications

General

Engine Brand	Kawasaki
Engine Displacement	726cc
Engine Model	FR730V
Cutting Width	54 inches
Max Speed	8 mph
Blade Tip Speed	18, 500 fpm
Transmission	Hydro-Gear 2800
Deck Material	7-gauge steel
Cutting Height	1.5" - 4.5"
Warranty	3 years
