SECTION 10: INSTRUMENTATION
10.1 Electronic Hour Meter—Registers Hour increments up to 9,999.9 total hours. This meter
records the cumulative time the engine is running.
10.2 Oil Pressure Light—This light comes on upon placing the ignition switch in the RUN
position and stays lit until the engine is running and a safe oil pressure is built up. If the
light comes on during operation, shut the engine off immediately and locate the problem or
contact authorized Bad Boy Mower dealer.
10.3 High Temperature Buzzer—Liquid-Cooled models are equipped with a buzzer that will
sound in the event of high water temperature.
IF THIS HAPPENS SHUT ENGINE OFF IMMEDIATELY! Allow engine to cool. Check for obstructions in
or around radiator or contact your local Bad Boy Mower Authorized Dealer.
10.1
10.1
PAGE 13
