(2) Front Tires (2) Actuator Blocks (2) Pivot Arms
(2) Front Forks (1) Pump idler
(4) Steering Arms (1) Deck Idler
Front Forks
Front Tires
Steering Arms
Actuator Blocks
Pump Idler
Deck Idler
Pivot Arms
If you purchased a ZT Series Mower,
your fuel tanks will not Swing-Away like
the illustration shown on this page.
The Swing Away feature is only
available on the Pup, Lighting, AOS,
and AOS Diesel Series
PAGE 15
