Bailey PAGEANT MONARCH - Page 11

11
SPECIFICATIONS
MODEL MAXIMUM M.R.O. MASS OF PAYLOAD PAYLOAD TOTAL
TECHNICAL ESSENTIAL ALLOWANCE ALLOWANCE USER
PERMISSIBLE HABITATION FOR FOR PAYLOAD
LADEN MASS EQUIPMENT PERSONAL OPTIONAL
EFFECTS EQUIPMENT EQUIPMENT
RANGER 380/2 997kg 827kg 58kg 94kg 18kg 170kg
RANGER 460/4 1208kg 944kg 68kg 124kg 22kg 214kg
RANGER 500/5 1268kg 1044kg 68kg 138kg 18kg 224kg
RANGER 520/4 1282kg 1060kg 68kg 132kg 22kg 222kg
RANGER 540/6 1306kg 1063kg 68kg 153kg 22kg 243kg
RANGER 620/6 1522kg 1272kg 68kg 160kg 22kg 250kg
RANGER GT60 380/2 1058kg 901kg 58kg 94kg 5kg 157kg
RANGER GT60 460/2 1177kg 1002kg 68kg 102kg 5kg 175kg
RANGER GT60 460/4 1252kg 1055kg 68kg 124kg 5kg 197kg
RANGER GT60 500/5 1316kg 1105kg 68kg 138kg 5kg 211kg
RANGER GT60 510/4 1281kg 1079kg 68kg 129kg 5kg 202kg
RANGER GT60 520/4 1326kg 1121kg 68kg 132kg 5kg 205kg
RANGER GT60 540/6 1350kg 1124kg 68kg 153kg 5kg 226kg
RANGER GT60 620/6 1566kg 1333kg 68kg 160kg 5kg 233kg
▲ The M.T.P.L.M. must not be exceeded. The maximum towing speed at M.T.P.L.M. for all models is 81 m.p.h. (130 k.m.p.h.)
▲ The maximum vertical static load for the coupling head or the maximum vertical load on the towing ball specified for the towing
vehicle must not be exceeded.
Steel wheel rim size: 5
1
/
2
J x 14 H2 ET30, 112mm PCD 5 stud. Alloy wheel rim size: 6J x 14 H2 ET30, 112mm PCD 5 stud
