9
Unicorn 2 Seville Madrid Valencia Cadiz Vigo Barcelona Cartagena Cordoba
Berths
2 4 4 4 4 4 4 4
Axles
1 1 1 1 1 2 2 2
Shipping Length
6424mm 7097mm 7341mm 7341mm 7341mm 7891mm 7891mm 7891mm
Internal Length
(Bed box Height)
4765mm 5438mm 5682mm 5682mm 5682mm 6232mm 6232mm 6232mm
Overall width
2280mm 2280mm 2280mm 2280mm 2280mm 2280mm 2280mm 2280mm
Overall Height
(incl aerial)
2610mm 2610mm 2610mm 2610mm 2610mm 2610mm 2610mm 2610mm
Maximum
Headroom
1960mm 1960mm 1960mm 1960mm 1960mm 1960mm 1960mm 1960mm
Body Length
(excluding hitch)
5504mm 6177mm 6421mm 6421mm 6421mm 6971mm 6971mm 6971mm
Tyre Sizes
185/R14 102R 185/R14 102R 185/R14 102R 185/R14 102R 185/R14 102R 185/65 R14 86T 185/65 R14 86T 185/65 R14 86T
Awning
Dimension
953mm 1020mm 1045mm 1045mm 1045mm 1093mm 1093mm 1093mm
Tyre Pressure
60Psi 60Psi 60Psi 60Psi 60Psi 35Psi 35Psi 35Psi
MRO
1225Kg 1329Kg 1343Kg 1344Kg 1344Kg 1526Kg 1519Kg 1497Kg
MTPLM
(Standard)
1350Kg 1484Kg 1497Kg 1498Kg 1498Kg 1686Kg 1679Kg 1657Kg
Opt Equipment
Payload
3Kg 3Kg 3Kg 3Kg 3Kg 3Kg 3Kg 3Kg
Total User
Payload
125Kg 155Kg 154Kg 154Kg 154Kg 160Kg 160Kg 160Kg
Static Load on
Coupling Head
100Kg 100Kg 100Kg 100Kg 100Kg 100Kg 100Kg 100Kg
Wheel bolt
Torque
130 Nm 130Nm 130Nm 130Nm 130Nm 130Nm 130Nm 130Nm
From the 2011 season the method of calculating the Mass in Running order (MRO) and user payload gures has changed in order to bring it in line with
European Vehicle Directives.
Allowances for essential equipment previously accounted for in the user payload are now either within the MRO (e.g. gas cylinders) or the personal
effects payload allowance (e.g. leisure battery)
Although the method of calculation has changed, the overall effect is that the amount of payload available to the customer has remained the same; it is just
calculated in another manner.
Awning sizes are ground to ground dimensions through the awning channel. These dimensions are issued as a guideline only; please refer to your dealer for the
correct awning size to suit your particular caravan.
