Document No
P/PR03/PB-D-H18650CH
A/05
Page
2/ 9
This spec manual is the enterprise standard of BAK Power, without authorization, any pirate or circulation is prohibited.
该规格书为比克动力企业标准,未经授权,不可翻印,传播.
Figure 3/ 图 3
4 Cell characteristics fresh cell tested at 22.5±2.5℃, standard charge and discharge unless otherwise
specified
电芯特性(除非有特殊说明,否则所有测试要求为:温度在 22.5±2.5℃条件下,样品为新电池,充放
电制度为标准充电和标准放电)
ITEM
项目
SPECIFICATION
规格
Nominal capacity
标称容量
2600 mAh@0.2C(500mA)
Minimum capacity
最小容量
2500 mAh@0.2C(500mA)
Nominal voltage
标称电压
3.6 V
Charge voltage(End current)
充电电压(截止电流)
4.2 V(25 mA)
Energy density
能量密度
200Wh/Kg
Discharge ending voltage
放电终止电压
2.75 V
Max charge current
最大充电电流
1C (2500mA) 20℃<T≤45℃
0.33C (830mA ) 10℃≤T≤20℃
0.1C (500mA) 10℃>T≥0℃
Max discharge current
最大放电电流
4C (10000mA) (25℃ continuous, not for cycle)
Storage temperature and time
存储温度和时间
45~60℃:1month(1 个月)
25~45℃: 3month(3 个月):
-20~25℃:12month(12 个月):
64.85±0.25
Ф18.35±0.15
