7
Programme overview also see Pa ge 5
After drying: laundry is to be ...
T-shirt
Shirts
Trousers
Skirts/dresses
Sportswear
Work clothing
Anoraks
Terry/
bathrobe
Underwear
Socks
Bed linen
Table linen
Terry towels
Tea towels/
towels
c
ironed

lightly ironed dry
@c
not ironed
c
passed through a mangle
resistentes/algod. (Cottons)
max. 6 kg For whites and coloureds/cotton or linen.
seco  (50 - 100 min.) (Iron Dry)
cø@c
è*è*è*è*è*è*è*è*
seco guardar (60 - 120 min.) (Cupboard Dry)
ccccccccc@
è*è*è*è*è*è*
sintéticos (Easy-Care)
max. 3 kg For non-iron laundry made of synthetic fibres and blended fabric, cotton.
seco  (20 - 30 min.) (Iron Dry)
cø@c
è*è*è*è*è*è*
seco guardar (20 - 40 min.) (Cupboard Dry)
ccccccccc@
è*è*
*
frio D (cold) max. 3 kg
For all types of fabrics. For freshening up or ai ring items of laundry that have been worn for a short period of time.
1010 / 9000400658 *400658*
Balay Electrogeräte GmbH
CarläWery Str. 34
81739 München / Germany
3SC60000EE
8
Installation
– Delivery specification: drye r, instructions for installation and use.
– Check dryer for transport d amage.
– The dryer is very heavy. D o not attempt to lift it on your own.
– Be careful to avoid sharp e dges.
– Do not lift the dryer by protru ding parts (e.g. the door) - risk of br eakage.
– Do not set up in a room th at is susceptible to frost.
Freezing water may cause damage.
– If in doubt, have the appliance connected by an expert.
Setting up the dryer
– The appliance plug mus t always be accessible.
– Ensure that the appliance is installed on a clean, level
and firm surface.
– Keep the air inlet on the fro nt of the dryer clear.
– Keep the area around the dryer clean.
– Adjust the height of the dr yer using the threaded
feet at the front.
Do not remove the threaded feet un der any
circumstances.
Mains connection safety information a page 11.
– Connect to an AC earthed s ocket. If in doubt have the socket che cked by an expert.
– The mains voltage and the voltage shown on the rating plate (aPage 9) must correspond.
– The connected load and necessary fuse protection are specified o n the rating plate.
Frost protection / Transport
Preparation
Empty the condensation container apage 4.
The dryer contains residual wate r;
this can flow out if the dryer is tilt ed.
1.
Take all accessory parts out
of the drum. The drum must
be empty.
Make sure that the air inlet
remains unobstructed
Clean and level
2.
Do not operate the dryer if there
is a danger of frost.
Do not install the dryer behind a door or sl iding
door, as these may prevent the dryer doo r from
opening.
Observing this instruction may stop a ch ild from
becoming shut inside the dryer and havin g its life
put in danger.
9
Technical data
Dimensions (DxWxH) 60 x 60 x 85 cm
Weight approximately 35 kg
Max. capacity 6 kg
Condensation container approx. 4.2 l
Ambient temperature 5 - 35 °C
Connection voltage 220 - 240 V
Connected load 2300 W
Fuse protection 10 A
Product number
a Rating plate or inside of the door
Production number
You can find the rating plate on th e back of the dryer.
ʠ
Consumption rates
These are guide values determin ed under standard
conditions. Deviations of up to 10 % a re possible.
Spin speed in rpm
(residual moisture)
Drying time** in
minutes, includ-
ing 8 minutes
cool cycle
Energy
consumption**
in kWh
resistentes/algod.
(Cottons) 6 kg
seco guardar
(Cupboard Dry)*
1400 (aprox. 50%) 100 3.20
1000 (aprox. 60%) 120 3.84
seco  (Iron Dry)* 1400 (aprox. 50%) 80 2.52
1000 (aprox. 60%) 100 3.02
800 (aprox. 70%) 12 0 3.53
sintéticos (Easy-Care)c3 kg
seco guardar
(Cupboard Dry)*
800 (aprox. 40%) 40 1.2 0
600 (aprox. 50%) 50 1.5 0
*Test program to DIN EN 61121.
**The values may deviate from the values shown here, because of over/undervoltage, type of
fabric, composition of the laundry to be dried, residual moisture in the material and size of the
load.
Optional accessories (o rder from the after-sales service using the order number)
Washer-dryer stack connection set
The dryer can be placed on top of a suitable washing machine with the same width and depth
to save space. This connection set must always be used to secure the dryer to the washing
machine. If the worktop of the washing machine is less than 544 mm deep , please consult
the after-sales service or your spec ialist retailer.
Platform
For easier loading and unloading. The bas ket in the pull-out can be used for c arrying the
laundry.
Installation underneath the worktop
Risk of electric shock.
Instead of the appliance covering pla te, you must have a metal cover fitted by an expert.
WZ
20311
WZ
20460
WZ
20295
10
What to do if ...
Repairs must only be carried out by the afteräsales service or an authoris ed expert.
Before you contact the after-sales service, please make sure that you are unable to resolve
the problem yourself. You will be charged for advice if a technician is called out, even during
the warranty period. You can find your nearest after-sales service in the enclosed list. Whe n
contacting the after-sales service, please quote the appliance's product number (E-Nr.) and
production number (FD) ( a on the insi de of the door).
ʠ
The $ inicio/stop (start/stop)
indicator light does not come on.
Mains plug plugged in?
Programme selected?
ʠ
The depósito (container)
filtro (clean) indicator light comes
on.
Empty the condensation co ntainer apage 4.
ʠ
The depósito (container)
filtro (clean) indicator light is
flashing.
Clean the fluff filter apag e 4.
Clean the air cooler if necessary a page 6.
ʠ
Dryer does not start. Has the $inicio/stop (start/stop) butto n been pressed?
Door closed?
Programme set?
ʠ
Programme stops shortly after it
has started.
Ambient temperature greater than 5 °C?
ʠ
Water is leaking out. Make sure the dryer is level.
ʠ
The door opens by itself. Push the door closed until you he ar it engage.
ʠ
The required degree of dryness
was not achieved or the drying
time was too long.
Clean the fluff filter apag e 4.
Empty the condensation co ntainer.
Ambient temperature higher tha n 35 °C a airing.
Air inlet may be blocked a keep unobstructed.
Was an unsuitable programme sel ected? apage 7.
Has the dryer been installed with sufficient space on all
sides? Ensure that air can circ ulate.
Mains failure a Restart the dryer.
ʠ
Laundry damp. Use the next drying programme up or use the timer
programme as a supplement apage 7.
Warm laundry feels damper th an it really is!
ʠ
The humidity in the room
has increased significantly.
Make sure the room is sufficien tly ventilated.
Air inlet blocked? a keep unobstructed .
Ensure that the air cooler is in us e.
ʠ
One or more indicator lights is/are
flashing.
Clean the air fluff filter and air co oler if necessary
apage 4/6.
Check the installation condition s apage 8.
Switch off, allow to cool, switch on a gain and restart the
programme.
ʠ
Mains failure. Remove laundry from the dryer im mediately and spread
out. This allows the heat to d issipate.
ʠ
If you cannot rectify a fault yoursel f or a repair is necessary:
– Set the programme selec tor to stop (Off).
– Remove the appliance plug from the socket.
– Call the after-sales service a after-sales service director y.
11
Safety instructions
Emergency – Pull the appliance plug out of the socket immediately or disc onnect the fuse.
ONLY use the
dryer...
– In rooms inside the house.
– To dry fabrics.
The dryer must
NEVER...
– Be used for other purp oses than those described above.
– Be modified in terms of its technology or attributes.
Dangers – The dryer must not be used by children or persons who have n ot been
instructed in its use.
– Do not leave children u nsupervised near the dryer.
– Keep pets away from th e dryer.
– Remove all objects from pockets.
Make especially sure that cigarette lighters are removed as they constitute an
a explosion hazard.
– Do not lean or sit on the do or a risk of tipping.
– Open the door carefull y. Hot steam may escape.
Installation – Secure loose cables a tripping hazard.
– Do not operate the drye r if there is a risk of frost.
Mains
connection
– Connect the dryer acc ording to specifications to an AC earthe d socket, as
otherwise it cannot be guarante ed that the appliance is completely safe.
– The cable cross-section m ust be sufficient.
– Only use earth-leakage circuit breakers with the following symb ol:
– The appliance plug a nd socket must be compatible.
– Do not use multiple plugs /couplings and/or extension cables.
– Do not touch or hold the appliance plug with wet hands
a risk of electric shock.
– Never pull the applianc e plug out of the socket by its cable.
– Do not damage the main s lead a risk of electric shock.
Operation – Only load the drum with laundry.
Check the contents before you swi tch the dryer on.
– Do not use the dryer if the laundry has been in contact with solvents, oil, wax,
grease or paint (e.g. hair setting s pray, nail polish remover, stain remover,
cleaning solvent, etc.) a fire/explosion hazard.
– Dust (e.g. coal dust, flour) poses a danger:
do not use the dryer a explosion hazard.
– Do not put laundry containing foamed material/rubber in the dryer a elastic
material may be destroyed and the dryer may be damaged due to possi ble
deformation of the foamed mat erial.
– Switch off the dryer once the programme has ended.
– Condensation is not dri nking water and may be contaminated wit h fluff.
Defect – Do not use the dryer if it is defective or if you suspect it is.
Repairs must only be carried o ut by the after-sales service.
– Do not use the dryer if th e mains cable is defective. To avoid d anger, only
have the defective mains cable re placed by the after-sales service.
Spare parts – Only use genuine spar e parts and accessories for safety reas ons.
Disposal – Dryer: pull out the appl iance plug, then cut off the mains cable from the
appliance. Dispose of the applian ce at a municipal waste disposal facil ity.
– Packaging: do not leav e children alone with packing parts
a risk of suffocation.
– All materials are environm entally safe and can be reused. D ispose of all
materials in an environmentally-res ponsible manner.
Instructions for
installation and use
en
T
umble dryer
Read these instructions before operating the dryer.
Observe the safety instructions on page 11.
