Baldwin Boxall Mitre Amplifiers - Mitre Mixer Overview

- 15 -
Issue 2
M
ITRE
M
IXER
The Mitre Mixer has all of the features of the Mitre Integrated Amplifiers but instead of producing a
100V line output to drive speakers directly, the output is a 0dB balanced line output to drive other
amplifiers.
The output is presented on two paralleled XLR connectors.
