- 28 -
Issue 2
REFIT SCREWS AND REPEAT
FOR OTHER SIDE.
2U CODE = M2RACK
3U CODE = M3RACK
CODE = MWALL
REPEAT FOR OTHER SIDE.
3 X HOLES FOR MOUNTING TO WALL
RECOMENDED SIZE = No10
AND ALIGN RACK BRACKET.
AND ALIGN WALL BRACKET. REFIT SCREWS AND
RACK & WALL MOUNTING ADAPTORS
REMOVE 3 x M3 SCREWS
REMOVE 2 x No4 SCREWS,
No4
No4
M3
M3
M3
FIG 12.
TO RACK MOUNT M2000,
TO WALL MOUNT M2000, REMOVE 3 x M3 SCREWS
BASE UNIT AND INSERT SCREW INTO REAR PANEL.
REPEAT FOR OTHER SIDE
SLOT IN COVER. (2 OFF)
INSERT BRACKETS INTO
REAR
OF
COVER
FIG 13.
STACKING ADAPTORS CODE = M2000SB
STACK M2000 ON TOP OF
