- 8 -
Issue 2
Mitre Slave Technical Specification
120W 300W
Rated output power
100V line 230V AC supply 120W 83 Ohms 300W 33 Ohms
THD 1 kHz rated output
230V AC supply Less than 0.5% typically 0.2%
Typical output power 1% THD
230V AC supply 150W 66 Ohms 360W 29 Ohms
Output regulation
1 kHz 100V line Better than 1 dB
Output voltages obtainable by pin selection 50 & 100V
Supply voltage AC 230V 50-60 Hz
Power consumption
Quiescent
Rated output power @ 1 kHz
18VA
300VA
26VA
700VA
Fuse protection
1 x AC supply 20 x 5 mm
2 x DC (amplifier) auto blade type
1 x DC Aux output 20 x 5 mm
3.15A(T)
10A(F)
2A(T)
6.3A(T)
20A(F)
2A(T)
Input type 2 x line balanced with priority gating
Input sensitivity 0.5V @ 40K Ohms balanced
Input common mode rejection ratio
50 Hz - 30 kHz
Frequency response -3dB @
Signal to noise ratio
Selectable high pass filter
Better than 40 dB typically 60 dB
40 Hz - 20 kHz
Better than 85 dB
200 Hz 12 dB/octave
DC Aux output 30V @ 1.5A max.
LED indicators Output level indicator 5V 25V 50V 100V
Inputs busy, i.e. accessed
Terminations
AC supply input
Line signal inputs
DC Aux output
Loudspeaker line output
3-pin
4-pin
2-pin
3-pin
DIN IEC 6A
Screw terminated connector
Crimp terminated connector
Screw terminated connector
Dimensions (cm) (D x W x H) 340 x 430 x 90 340 x 430 x 132
Weight 11.5 Kg 17.5 Kg
