Balluff BNI IOL-309-002-Z019 - Default Chapter; Table of Contents

Balluff Network Interface / IO-Link BNI IOL-309-002-Z019
www.balluff.com
2
Contents
1 User Instructions 4
1.1. About This Manual 4
1.2. Structure of the Manual 4
1.3. Typographical Conventions 4
Enumerations 4
Actions 4
Syntax 4
Cross-references 4
1.4. Symbols 4
1.5. Abbreviations 4
1.6. Differing views 4
2 Safety 5
2.1. Intended use 5
2.2. Installation and Startup 5
2.3. General Safety Notes 5
2.4. Resistance to Aggressive Substances 5
Dangerous voltage 5
3 First Steps 6
3.1. Connection Overview 6
3.2. Mechanical Connection 7
3.3. Electrical Connection 7
Functional ground 7
IO-Link connection 7
Connecting the sensor hub 8
Module variants 8
Sensor/actuator interface 8
Extension port 8
4 General Configuration 9
4.1. Extension port 9
Extension port configuration 55
hex
9
Setting the serial number 54
hex
9
5 Configuration: "Extension Off" 10
5.1. IO-Link Data 10
5.2. Process Data Input 10
5.3. Process Data Ouput 10
5.4. Parameter Data/Demand Data 11
Parameter Data/Demand Data 11
Inversion of the inputs 40
hex
12
Configuration In-Outputs 41
hex
12
Safe state of Outputs 42
hex
12
Voltage monitoring 44
hex
14
Monitoring the outputs 45
hex
14
6 Configuration: extended with BNI IOL-102-002-Z019 15
6.1. IO-Link Data 15
6.2. Process Data/Input Data 15
6.3. Process Data/ Output Data 16
6.4. Parameter Data/Demand Data 17
Parameter Data/Demand Data 17
Inversion of the inputs 40
hex
18
Configuration In-/Output 41
hex
18
Safe state of Outputs 42
hex
19
Safe state of the outputs on Pin 4 42
hex
19
Voltage monitoring 44
hex
20
Monitoring the outputs 45
hex
20
Setting the serial number 54
hex
20
