Banner B2036 - Assembly Instructions; Caster Installation; Assembled Creeper Reference; Specifications

4 pages

To Next Page

To Previous Page

Fig.1

Fig.2

Caster

Lock Pin

Head Cushion

Head Frame

Middle Frame

Rear Frame

Locking Pin

Casters (4)

Casters (2)

Nuts (4)

SPECIFICATIONS

Model WeightCapacity Dimensions(LxWxH) Contents

B2036 300 lbs 36"x16-5/8"x4-5/8" 1 Creeper Body, 6 Casters, 4 Nuts

Assembly Instructions:

1.Insert the 6 casters into the frame of assembled creeper body so that caster wheels will contact oor. Use

appropiatewrench toxthehead frame casters, andusea hex. key (5mm,notprovided) to fasten withthe

providednutsformiddleandrearframecasters.

2.RefertoFig.2fortheassembledcreeper.

Reference
