R5911443 /11 UDM216
Specification Value
2 Column mode (2x1
layout)
• 1920 x 2160 @50 Hz
• 1920 x 2160 @60 Hz
• 2048 x 2160 @50 Hz
• 2048 x 2400 @60 Hz
Native video timings
• UDM-W: 1920 x 1200 @60 Hz
• UDM-4K: 3840 x 2160 @60 Hz
CAUTION: The HDBaseT inputs can bridge a distance of 100 m but are sensitive to radiated
electromagnetic interference: radiated electromagnetic interference (e.g. from GSM or switching
inductive or capacitive loads) within the limits of electromagnetic compatibility requirements of 3 V/m
can cause random flashes or temporary loss of the projected image.
As such, shielded CAT-6 cables with metal RJ-45 connectors are recommended; choose cable
length no longer than required and route HDBT cable optimally screened from possible sources of
electromagnetic emission.
A.11 Specifications DisplayPort 1.2 inputs
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
DisplayPort 1.2 specifications
Pixel rate Up to 600 MHz pixel clock
Color space
• YCbCr 4:2:2
• YCbCr 4:4:4
• RGB 4:4:4
Color depth
• 24 bpp
• 30 bpp
• 36 bpp
Data rate support
• 1.62 Gbps: Reduced Bit Rate (RBR)
• 2.7 Gbps: High Bit Rate (HBR)
• 5.4 Gbps: High Bit Rate 2 (HBR2)
For future release
• Interlaced support
• HDCP 1.4
Audio not supported
3D support
• Field sequential 3D (Active 3D)
• Passive stereoscopic 3D (Passive stereo) converted to active 3D
Video timings
progressive
10
2D / 3D Layout Mode
11
Supported formats
2D Standard layout (1x1
layout)
• Up to 4096 x 2160 @24 Hz
• Up to 4096 x 2160 @30 Hz
• Up to 2048 x 1080 @48 Hz
• Up to 4096 x 2160 @50 Hz
• Up to 4096 x 2160 @60 Hz
• Up to 2560 x 1600 @120 Hz
2D 2 column mode (2x1
layout)
• 1920 x 2160 @60 Hz
• 1920 x 2160 @120 Hz
Specifications
10. For the full list of video timings, see Appendix
11. Only 1x1 layout is supported on the Quad Combo input Mk1 and Mk2. The Quad DP1.2 input supports all layout configurations.
