LEGENDA - LEGENDE - KEY - LEGENDE - LEYENDA - LEGENDA
G Attacco arrivo gas - Gasanschuluss - Gas connection -
Arriveè gaz - Union da gaas - Gasaansluiting
EN 10226-1 R 1/2; EN ISO 228-1 G 1/2 (DK)
MISURE IN mm - DIMENSIONS IN mm - ABMESSUNGEN IN mm
MESURES EN mm - MEDIDAS EN mm - MATEN IN mm
75 250 75 75 450 75 75 650 75
7FRI/G415 7FRI/G610 7FRI/G815
150 720
870
21,5
94,5 480
1070
G
700
400 600 800
45 45 45
446
G
G
G
11
