4. Place the 115V / 12VDC pump assembly in the
sump basin.
5. Measure the distance between the household
discharge pipe and the top of the115V / 12V DC
pump assembly. Cut Sched 40 PVC pipe to fit
this measurement.
Household
discharge
piping
Flex
coupling
5
4
INSTALLATION INSTRUCTIONS
6. Dry-fit the pipe connections to be sure measurements
are connected. Insert the new connecting pipe into
the top of the pump assembly flex coupling. Glue the
connecting pipe to the household discharge pipe with
PVC glue and primer. Securely tighten the clamps on
the flex coupling.
Sched 40 PVC
6
