32
Zenith aps seRies
SERVICE/REPLACEMENT PART RECORD (Page 2)
DOUBLE T-CABLE
Part Number Description QTY Order Date Price
999-0806-200SP Double “T” Control Cable 1 Cable
Deck Hardware Pack - INCLUDES . . . 1 Pkg
2 Split Stem Cable Retainer
4 Push Cable Ties
8 Standard Cable Ties
1 Installation Instruction Sheet
UNDERBED LIGHT
Part Number Description QTY Order Date Price
999-0806-220SP Underbed Light Unit 1 Motor
Motor Hardware Pack - INCLUDES . . . 1 Pkg
12 Adaptor Cable - 999-0806-212
4 Standard Cable Ties
1 Attachment Material
1 Installation Instruction Sheet
STAFF CONTROL
Part Number Description QTY Order Date Price
999-0831-901
Switch Pad with Bezel & Cables 1 Unit
ZL831000
Staff Control Service Pack - INCLUDES . . . 1 Pkg
PLEASE SEE
PAGE 11
FOR
INSTALLATION
INSTRUCTIONS
1 Switch Pad with Bezel & Cables
1 Shroud (Cable Cover)
6 #6 Phillips Head Truss Screws
3 4” Nylon Cable Tie
1 Installation Instruction Sheet
CAPS & PLUGS
Part Number Description QTY Order Date Price
NOTE: CAPS & PLUGS CAN ONLY BE PURCHASED IN SETS OF 12
100-4200-004PK
1.25” x 1.25” Square Caps Pack
12/pkg
100-4700-017PK 1.00” x 2.00” Rectangular Caps Pack 12/pkg
100-4700-018PK 1.25” x 2.00” Rectangular Caps Pack 12/pkg
100-4715-011PK 1.50” Round End Caps Pack (cover arm bearings) 12/pkg
999-0775-001PK Half Moon End Caps Pack (caster bases) 12/pkg
100-4762-002PK 5/8” Round Plugs Pack (both sides of foot deck) 12/pkg
100-4738-005PK 3/8” Round Plugs (on main frame rails - foot end) 12/pkg
FOR GENERAL CAP/PLUG DIAGRAMS PLEASE SEE PAGES 36 & 37
