BASKETBALL PROBASE PROBASE - Product Components; Component Identification

- 3 -
*For assemblies including ange nuts (intergrated washer nuts), you will not have at washers in your kit.
INSTALLATION GUIDE
COMPONENTS
A
Stake (2 identical components)
B
Main pole holder
C
Pivot
D
Pivot base
E
Removable front cover
F
Pressure plate
G
Tapping block (plastic or wood)
H
Tapping block Holder
I
Handle bolts
J
Bolts
K
Nuts
L
Flat washers
*
M
Self-adhesive rubber pad
(included only with plastic
tapping blocks)
A
B
C
EF
G H MH
I
D
J
K
L
