www.batcafitness.com 19 Fusion 2 Owner’s Manual
Step 9:
Figure 9
Item # Part # Description Qty
42 BFM-10586 Leg Extension Arm Assembly 1
44 BFL-50207 Hold Down Adjustment Plate 1
45 BFL-50211 Plate 1
46 BFM-10587 Knee Hold Down Assembly 1
47 BFM-51094 2” Axle 1
55 BFH-50165 1" Snap Ring 2
56 BFH-50146 3/8" Flat Washer (Black) 6
58 BFH-50157 3/8"-16 Nylock (Black) 3
63 BFH-50125 HCS 3/8"-16 X 3" P5 3
182 BFH-50337 Wavy Washer 1
All Flat Washers and Nylocks are 3/8” unless otherwise noted.
To Next Page
