Batca Fitness Systems 28 Fusion 2 Owner's Manual
Figure 18
Item # Part # Description Qty
157 BFM-10605 Leg Press Frame 1
158 BFM-10575 Leg Press Connector 1
56 BFH-50146 3/8" Flat Washer (Black) 4
59 BFH-50270 HCS 3/8"-16 X 5 1/4" P5 2
99 BFH-50149 3/8"-16 Jam Nut (Zinc) 1
58 BFH-50157 3/8"-16 Nylock (Black) 2
181 BFH-50339 Large Flat Leveler 1
All Flat Washers and Nylocks are 3/8” unless otherwise noted.
Step 18:
Leg Press Option
