www.batcafitness.com 41 Fusion 2 Owner’s Manual
The Fusion without Leg Press has a layout dimension of 3’-11” (width) x 5’-11 1/4” (length) x 6’-11”
(height). There should be a minimum of 18”, preferably 24”, of working space around the entire unit.
Layout Diagram without Leg Press
