Page 6 For technical questions, please call 1-888-866-5797. Item 58608
SAFETY OPERATION MAINTENANCESETUP
Specifications
Battery Type 20V Bauer Li-ion (64816, 57007)
Charger Type 20V Bauer Li-ion (57006)
Maximum Pressure 10,000 PSI
Grease Cartridge Capacity 14.5 oz.
Maximum Flow Rate 5 oz/min.
Hose Outlet Threads (Tool) 7/16 UNEF
Hose Outlet Threads
(Coupler Side)
1/8" NPT
Outlet Threads (Filler Port) 1/8″ NPT
Hose Length 36″
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Note: For additional information regarding the parts listed in the
following pages, refer to Parts List and Diagram on page 12.
Charging
Follow instructions included with the Charger, sold separately.
Functions
Grease
Coupler
36″ Hose
Grease
Tube
Variable Speed
Trigger
Pressure
Relief Valve
Air Bleed
Valve
Follower Rod
Handle
Motor
End Cap
LED
Light
Bulk Loading
Port
To Next Page
