5
Dip Switch Compatibility List
Below are some of the more common compatibility settings:
• For Boss effect units that require a PSA power supply please
position the Dip Switch DOWN.
• For Boss effect units that require a ACA power supply please
position the Dip Switch UP.
• For Line 6 effect units such as: DL4, DM4, FM4 and MM4
please use Outputs 5 and 6, position the Dip Switch UP and
only use Red 2.1-2.5 barrel cables.
