component name specification package
1
carbon film
resistor
47 1/4W FTP=10mm R45
2
carbon film
resistor
100 1/4W
FTP=10mm R48
3
carbon film
resistor
470 1/4W
FTP=10mm
R1 R2 R3 R4 R5 R6 R7 R8
R9 R10 R11 R12 R13 R14 R76
R77 R79 R100 R112 R115
4
carbon film
resistor
680 1/4W FTP=10mm R29
5
carbon film
resistor
1K 1/4W FTP=10mm R81 R85 R88 R93
6
carbon film
resistor
2.2K 1/4W FTP=10mm R46 R47
7
carbon film
resistor
5.6K 1/4W FTP=10mm R80 R84 R87 R111
8
carbon film
resistor
10K 1/4W FTP=10mm
R37 R39 R42 R57 R58 R65 R66
R70 R71 R68 R69 R117 R54
9
carbon film
resistor
22K 1/4W FTP=10mm
R34 R35 R36 R38 R40 R41 R102
R103 R104 R105 R106 R107
10
carbon film
resistor
47K 1/4W FTP=10mm
R15 R16 R17 R18 R19 R20 R21
R22 R23 R24 R25 R26 R27
R28 R43 R44 R49 R50 R51 R52
R53 R54 R72 R73 R74 R75
R78 R82 R83 R86 R89 R90 R91
R92 R94 R95 R96 R99 R110
R116 R114 R118
11
carbon film
resistor
47K 1/4W
R74 R95 R96
12
carbon film
resistor
56K 1/4W FTP=10mm
R97 R98
13
carbon film
resistor
100K 1/4W FTP=10mm
R30 R31 R32 R33 R56 R59 R60
R61 R62 R63 R64 R67 R109
14 jumper wire 5mm
J15 J45 J46 J52 J53 J56 J57 J59
J62 J65 J72 J80
15 jumper wire 7.5mm
J6 J12 J16 J17 J18 J22 J23 J27
J30 J32 J33 J37 J38 J44 J47
J48 J54 J55 J58 J67 J68 J69 J74
16 jumper wire 10mm
J2 J11 J13 J14 J20 J24 J25 J26
J28 J31 J35 J36 J37 J42 J49
J50 J51 J55 J61 J63 J66 J71 J78
17 jumper wire 12mm
J1 J3 J4 J8 J9 J19 J20 J21 J29
J34 J39 J40 J43
18 jumper wire 15mm
J10 J41 J60
19 jumper wire 17.5mm J7
20 elect.cap. 1UF/50V FTP=2.5mm
C46 C48
21 elect.cap. 4.7UF/50V FTP=2.5mm
C47 C49
22 elect.cap. 10UF/50V FTP=2.5mm
C1 C2 C6 C7 C10 C11 C12
C13 C14 C15 C16 C28 C29 C30
C31 C32 C33 C34 C39 C40
C54 C58 C59 C60 C61 C64 C65
description
no.
quantity/
unit
components position no.
additional
explaination
AV212T input board
