component name specification package
1
carbon film
resistor
10 1/4W
FTP=10mm R11
2
carbon film
resistor
68 1/4W
FTP=10mm R23
3
carbon film
resistor
470 1/4W
FTP=10mm
R22 R32 R33 R37
4
carbon film
resistor
1K 1/4W FTP=10mm R48
5
carbon film
resistor
1.5K 1/4W FTP=10mm
R18 R20 R35
6
carbon film
resistor
1.8K 1/4W FTP=10mm R17
7
carbon film
resistor
2.2K 1/4W FTP=10mm R40
8
carbon film
resistor
4.7K 1/4W FTP=10mm
R24 R34
9
carbon film
resistor
5.6K 1/4W FTP=10mm
R12 R13
10
carbon film
resistor
10K 1/4W FTP=10mm
R5 R6 R7 R8 R9 R10 R14 R15
R16 R19 R21 R26 R27 R39
R44 R50 R51
11
carbon film
resistor
15K 1/4W FTP=10mm
R4 R38 R47
12
carbon film
resistor
22K 1/4W FTP=10mm
R3 R28 R29 R30 R31 R36 R41
R42 R43 R45 R46 R49 R53
13
carbon film
resistor
47K 1/4W FTP=10mm
R1 R25
14
carbon film
resistor
100K 1/4W FTP=10mm
R2 R52
15 elect. cap. 2.2UF/50V FTP=2.5mm
C12 C17 C18 C25 C26 C27 C30
C31 C33 C43 C44 C45
16 elect. cap. 4.7UF/50V FTP=2.5mm
C29 C37
17 elect. cap. 10UF/50V FTP=2.5mm
C32 C40
18 elect. cap. 22UF/16V FTP=2.5mm C20
19 elect. cap. 47UF/16V FTP=2.5mm
C4 C10 C19 C34 C38
20 ceramic cap. 561/50V FTP=2.5mm
C5 C8
21 ceramic cap. 101/50V FTP=2.5mm
C28 C39
22 ceramic cap. 22P/50V FTP=2.5mm
C36 C41
23 ceramic cap. 47P50V FTP=2.5mm
C35 C42
24 CBB cap. 332J/50V FTP=3.5mm C1
25 CBB cap. 823J50V FTP=3.5mm
C6 C7
26 CBB cap. 272J/50V FTP=3.5mm
C21 C22
27 CBB cap. 562J/50V FTP=3.5mm C11
28 CBB cap. 104J50V FTP=3.5mm
C2 C3 C9 C13 C14 C15 C16
C23 C24
29 integrate circuit PT2399 DIP16 IC1
30 integrate circuit PT2313BL SMD28 IC2
31 integrate circuit JRC4558 DIP8
IC3 IC5
AV212T OK board
no.
description
quantity/
unit
components position no.
additional
explaination
