PRODUCT ASSEMBLY
2
1
Locate the part 5 handlebar shaft, remove the hardware and set aside.
Slide the handlebar shaft into the part A main frame above the wheel. Place two washers from
the removed hardware set onto the handlebar shaft, one washer per side.
Locate the part B front stabilizer and attach it to the front of the part A main frame with two
part 1 bolt sets. Repeat to attach the part C rear stabilizer.
NOTE: The front stabilizer has a set of wheels for moving your elliptical bike.
C
B
1
x4
A
| 5
5
5
