BCP SKY907 - Step 2 & 3: Wheel and Axle Assembly

Slide on a part 2 washer, part D front wheel, and another part 2 washer onto a front wheel axle and secure
it with a part 3 pin. Repeat on the other side. Snap a part F hub cap onto each wheel.
Insert a part G gear box into one side of the axle. Route the wires from the gear box through the body of
the vehicle and into the seat. Slide on a part E rear wheel, and part 2 washer onto the rear axle and secure
it with a part 3 pin. Repeat on the other side. Snap a part F hub cap onto each wheel.
3
PRODUCT ASSEMBLY
Pg. 6
2
Slide the part C rear axle through the body of the vehicle.
DF
2
3
EF
2
3
E
C
G
F
2
3
D F
3
2
G
