Guidance and manufacturer’s declaration — electromagnetic immunity
REF 5513E/5514 series is intended for use in the electromagnetic environment specified below.
The customer or the user of REF 5513E/5514 series should insure that it is used in such an environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic environment - guidance
Electrostatic discharge (ESD)
IEC 61000-4-2
±8 kV contact
±2/4/8/15 kV air
±8 kV contact
±2/4/8/15 kV air
Floors should be wood, concrete or ceramic
tile. If floors are covered with synthetic
material, the relative humidity should be at
least 30%.
Electrical fast transient/burst
IEC 61000-4-4
±2 kV for power supply lines
100kHz repetition frequency
±2 kV for power supply lines
100kHz repetition frequency
Mains power quality should be that of a
typical commercial or hospital environment.
Surge
IEC 61000-4-5
±0.5/1kV line to line ±0.5/1kV line to line
Mains power quality should be that of a
typical commercial or hospital environment.
Voltage dips, short
interruptions and voltage
variations on power supply
input lines
IEC 61000-4-11
0% UΤ; 0.5 cycle at 0°, 45°, 90°,
135°, 180°, 225°, 270°and 315°
0% UΤ; 1 cycle and
70% UΤ; 25/30 cycles
Single phase: at 0°
0% UΤ: 250/300 cycle
0% UΤ; 0.5 cycle at 0°, 45°, 90°,
135°, 180°, 225°, 270°and 315°
0% UΤ; 1 cycle and
70% UΤ; 25 cycles
Single phase: at 0°
0% UΤ: 250 cycle
Mains power quality should be that of a
typical commercial or hospital environment.
Power frequency (50/60 Hz)
magnetic field
IEC 61000-4-8
30 A/m
50 Hz/60Hz
30 A/m
50 Hz/60Hz
Power frequency magnetic fields should be at
levels characteristic of a typical location in a
typical commercial or hospital environment.
Note: UΤ is the a.c. mains voltage prior to application of the test level
