1
Dimmer
000-255
Master dimmer
2
000-255
All Red (0-100%)
3
000-255
All Green (0-100%)
4
000-255
All Blue (0-100%)
5
000-255
All White (0-100%)
6
Strobe
000-009
No function
010-255
Slow- fast
7
000-255
Background color red dimming in the effect mode (0-100%)
8
000-255
Background color green dimming in the effect mode (0-100%)
9
000-255
Background color blue dimming in the effect mode (0-100%)
10
5050RGB Effect Channel
000-005
CH2-4 No function
006-011
Pattern effect 1 (CH2-4 controls the pattern color, CH7-9 controls background
color)
012-017
Pattern effect 2 (CH2-4 controls the pattern color, CH7-9 controls background
color)
…
…
222-227
Pattern effect 37 (CH2-4 controls the pattern color, CH7-9 controls
background color)
228-233
Auto effect (Circle running pattern effect 1-37, CH2-4 controls the pattern
color, CH7-9 controls background color)
234-236
Sound 1 (CH11 is invalid)
237-239
Sound 2 (CH11 is invalid)
240-242
Sound 3 (CH11 is invalid)
243-255
Sound 4 (CH11 is invalid)
11
5730-W Effect Channel
000-006
CH5 No function
007-013
Effect 1
014-020
Effect 2
…
...
224-230
Effect 32
231-255
Auto effect (Circle running pattern effect 1-32)
12
000-255
DMX program speed (slow-fast)
