Beamz PLS15 - Page 26

26
MENU / MENÜ / MENÚ
d001. Setting DMX address
d512.
U.000
U.255
F.000
F.255
F001-F010 Sound control
F011-F255 Strobe with speed increasing
Menu
d001.
U.000
F.000
Dimmer
Sound + Strobe function
F000 0-100%
DMX CHANNELS / DMX KANALEN / DMX-KANÄLE / CANALES DMX /
CANAUX DMX / KANAŁY DMX
Channel
Function
Value
Description
1
Dimmer
000-255
Dimmer 0-100%
2
Sound / strobe
000-000
No function
001-010
Sound control
011-255
Strobe (slow to fast)
TECHNICAL SPECIFICATION / TECHNISCHE SPECIFICATIE / TECHNISCHE
DATEN / ESPECIFICACIONES TÉCNICAS / SPÉCIFICATIONS TECHNIQUES /
SPECYFIKACJA TECHNICZNA
Rated voltage : 5V/650mAh
Rated power : 8 Watt
LED : 120 SMD White (153.246) / UV (153.249) LEDs
DMX Channels : 2 Channels
Function : DMX, Auto, Sound active, Master-Slave and IRC.
Dimensions per unit : 120 x 160 x 115mm
Weight (per unit) : 0.5kg
The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can
be changed without prior notice.
