System Components
DxC Systems
UniCel DxC Systems Instructions For Use A13914 System Description
October 2005 Page 2-5
2
System Components
DxC Systems
A UniCel DxC System can be divided into the following components:
• Sample Handling Components
• Modular Chemistry System
• Cartridge Chemistry Reagent Handling System
• Hydropneumatic System
• Operation and Control Components
A Closed Tube Sampling System has optional components listed below:
• Large Particle Immuno Assay Module (LPIA)
*
• Closed Tube Sampling (CTS)
Figure 2.1 UniCel DxC 600 Analyzer
*
Equivalent to Near Infrared Particle Immuno Assay (NIPIA).
1. Modular Chemistry (MC) Section
2. Cartridge Chemistry (CC) Portion
3. Autoloader
4. Reaction Carousel
5. Dual Reagent Carousel
6. Operator Console
A015900P.EPS
54
3
1
2
6
