BED BATH & Beyond WF307716 - Page 4

4
12 13
DESK = 1 PC (MDF)
SHELF (i) = 1 PC (MDF)
29 30
2827
BACK PANEL = 2 PCS
SIDE PANEL = 2 PCS
TOP/BOTTOM PANEL = 2 PCS
26
Hardware List - WF307717
ASSEMBLY TOOLS REQUIRED ( NOT INCLUDED )
PLEASE BE CAREFULL DO NOT DAMAGE THE HOLE
POSITION WHEN YOU USE POWER TOOLS !
JCBC BOLT
M6 x 90mm
32 pcs
A
JCBC BOLT
M6 x 55mm
46 pcs
B
C
JCBC BOLT
M6 x 30mm
19 pcs
D
BARREL NUT
M6 x 13mm
32 pcs
E
WOOD DOWEL
M10 x 40mm
26 pcs
F
PAN HEAD SCREW
M4 x 25mm
26 pcs
CSK SCREW
M3.5 x 16mm
110 PCS
G
DOOR KNOB
2 PCS
H
HINGES
6 PCS
MAGNET
4 PCS
I J
CHROME PIPE
1 PC
L
PAN HEAD SCREW
M4 x 32mm
14 pcs
M
K
CHROME PIPE HOOK
2 PCS
N
CORNER ARM
8 pcs
LVL BED SLAT = 13 PCS
ALLEN KEY
1 pc
O Q
WOOD DOWEL
M8 x 30mm
28 pcs
BLOCK FOR SLAT
ASSEMBLY
80MM X 80MM X6MM - 1PC
R
DOOR PANEL = 2 PCS (MDF)
S
L-BRACKET (ii)
20 pcs
T
CSK SCREW
M3.5 x 10mm
16 PCS
TRUSS HEAD SCREW
M4 X 25mm
2 pcs
P
WF307716/WF307717
11
SHELF (ii) = 2 PCS (MDF)
Part List - WF307716
