5
5. Fit the Wire Shelf
[ 4 x A1, 4 x B ]
The Wire Shelf (7) has two plates, and two hooks. The hooks are facing forward, and will engage into the Front Shelf
Brackets (3) assembled in step 1. The plates have two holes each through which screws go into Back Leg:
6. Place the Cylinder Shield
[ 6 x C, 6 x E ]
The Cylinder Shield (11) is attached to the rear leg by six screws and washers, three each side. Ensure the shield is
curved towards the front:
