Behringer S16 - Stage Box Deployment; X32 Console and P-16 System Setup

S16
I/O Box with 16 Remote-Controllable MIDAS-designed Preamps, 8 Outputs and
AES50 Networking featuring KLARK TEKNIK SuperMac Technology
4
Operation Mode Chart
Seq.
LED
SN MASTER
sync clock
LED
SPLITTER
LED
OUT +16
LED
OUT +8
XLR analog
out 1-8
ADAT
out 1-8
ADAT
out 9-16
P-16 Ultranet
out 1-16
1 (default)
AES50
(console)
= AES50-A
ch01-ch08
= AES50-A
ch17-ch24
= AES50-A
ch25-ch32
= AES50-A
ch33-ch48
2
AES50
(console)
on
= AES50-A
ch09-ch16
= AES50-A
ch17-ch24
= AES50-A
ch25-ch32
= AES50-A
ch33-ch48
3
AES50
(console)
on
= AES50-A
ch17-ch24
= AES50-A
ch17-ch24
= AES50-A
ch25-ch32
= AES50-A
ch33-ch48
4
AES50
(console)
on
= AES50-A
ch01-ch08
= Local In
01 - 08
= Local In
09 - 16
= Local In
01 - 16
5
AES50
(console)
on on
= AES50-A
ch09-ch16
= Local In
01 - 08
= Local In
09 - 16
= Local In
01 - 16
6
AES50
(console)
on on
= AES50-A
ch17-ch24
= Local In
01 - 08
= Local In
09 - 16
= Local In
01 - 16
7 on
48 kHz
(int)
= AES50-A
ch01-ch08
= AES50-A
ch01-ch08
= AES50-A
ch09-ch16
= AES50-A
ch01-ch16
8 on
44.1 kHz
(int)
= AES50-A
ch01-ch08
= AES50-A
ch01-ch08
= AES50-A
ch09-ch16
= AES50-A
ch01-ch16
9 on
48 kHz
(int)
on
= AES50-A
ch01-ch08
= Local In
01 - 08
= Local In
09 - 16
= Local In
01 - 16
10 on
44.1 kHz
(int)
on
= AES50-A
ch01-ch08
= Local In
01 - 08
= Local In
09 - 16
= Local In
01 - 16
