Specications
Processing
A/D-D/A conversion (Cirrus Logic A/D CS5368, D/A CS4385) 24-bit @ 44.1 / 48 kHz, 114 dB dynamic range
Networked I/O latency (stagebox in > console processing* > stagebox out) 1.1 ms
Connectors
XLR inputs, programmable mic preamps, designed by MIDAS 16
XLR outputs 8
Phones outputs, ¼" TRS 1 (mono)
AES50 ports, SuperMAC 2
P-16 connector, Ultranet (no power supplied) 1
MIDI inputs / outputs 1 /1
ADAT Toslink outputs (2x 8 Ch) 2
USB type B, rear panel, for system updates 1
Mic Input Characteristics
Design MIDAS
THD + noise, 20 dB gain, 0 dBu out < 0.006 % A-weighted
Input impedance XLR, unbal. / bal. 5 kΩ / 10 kΩ
Non clip maximum input level, XLR +23 dBu
Phantom power, switchable per input 48 V
Equivalent input noise level, XLR (input shorted) -128 dBu
CMRR, XLR, @ 20 dB gain (typical) > 70 dB
CMRR, XLR, @ 40 dB gain > 80 dB
Input/Output Characteristics
Frequency range, @ 48 kHz sample rate, 0 dB to -1 dB 10 Hz - 22 kHz
Dynamic range, analog in to analog out (typical) 106 dB
A/D dynamic range, preamp and converter (typical) 109 dB
D/A dynamic range, converter and output 108 dB
Cross talk rejection @ 1 kHz, adjacent channels 100 dB
Output level, XLR, nom./max. +4 dBu / +21 dBu
Output impedance, XLR, unbal. / bal. 75 Ω / 75 Ω
Phones output impedance / level 40 Ω / +25 dBm (mono)
Residual noise level, XLR and TRS -87 dBu A-weighted
Indicators
Display 4-digit, 7-segment, LED
Front status LEDs
AES50-A, red/green; AES50-B, red/green; HA Locked, red;
SN Master, green; Splitter, orange; Out +16, orange; Out +8, orange
Meter Sig, -30 dB, -18 dB, -12 dB, -9 dB, -6 dB, -3 dB, Clip
Rear panel Splitter mode, orange
Power
Switch-mode autorange power supply 100-240 V (50/60 Hz)
Power consumption 45 W
Physical
Dimensions 19 x 8.9 x 3.5" / 482 x 225 x 89 mm
Weight 10.4 lbs / 4.7 kg
*) incl. all channel and bus processing, excl. insert eects and line delays
S16
Digital Snake I/O
