Behringer T-1 User Manual

3 TUBE CONDENSER MICROPHONE T-1 User Manual
At a Glance1.
Mount the microphone(1)
Connect the microphoneto the PSU-T(2)
Connect the PSU-T to the mixer(3)
Connect the mains cable(4)
Switch on the PSU-T(5)
Allow the tube to warm up(6)
And you're good to go!
(1)
(2) (3)
(4)(5)
(6)

Behringer T-1 Specifications

Physical Dimensions

transducer type	16 mm (0.63")
dimensions	shaft: 68 mm, length: 211 mm
weight	0.77 kg

Audio Specifications

frequency response	20 Hz to 20 kHz
open circuit sensitivity	-40 dBV (0 dBV = 1 V/Pa)
max SPL	130 dB

Electrical Specifications

nominal impedance	approx. 200 Ω
supply voltage adapter	BEHRINGER PSU-T
mains voltage	100-120 V~, 50/60 Hz T 250 mA H 250 V / 220-230 V~, 50/60 Hz T 125 mA H 250 V
