Input gain
control
Channel signal
indicator
Channel clip
indicator
SYNC Master and
Locked indicators
+48 phantom
power switch
Power switch
ADAT optical
output
Word clock
input
XLR balanced/unbalanced
outputs
IEC power socket ADAT optical input
SYNC Word clock
setting selector
¼" Line
level input
MIDAS designed
mic preamp
ADA8200 Front Panel
ADA8200 Rear Panel
ULTRAGAIN
DIGITAL
ADA8200

Other manuals for Behringer ULTRAGAIN DIGITAL ADA8200

Preview: Quick Start Guide
Quick Start Guide15 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Behringer ULTRAGAIN DIGITAL ADA8200 and is the answer not in the manual?

Behringer ULTRAGAIN DIGITAL ADA8200 Specifications

General IconGeneral
Sample rate48 kHz
Frequency range10 - 24000 Hz
Channels quantity8 channels
Digital sound processing24 bit
Microphone input impedance2700 Ω
Total Harmonic Distortion (THD)0.008 %
XLR out8
DJ mixerNo
Power consumption (typical)15 W
Weight and Dimensions IconWeight and Dimensions
Depth217 mm
Width482.6 mm
Height44.5 mm
Weight2100 g
